Hand-wound EGODRIFT Tengu 4025HT motor for the Kraken 580 and other 6S high-kV setups in the 550-600mm class. The motor comes with a kV rating of 1190kV and features a modified base for yet improved cooling and performance.
Specifications
- Manufacturer: EGODRIFT
- Stator size: 4025
- Motor configuration: 12N10P
- Wire colour: Copper
- Motor wire type: High temperature copper wire
- Motor wire: 1.5mm
- Motor kV: 1190 kV
- Motor shaft: Hardened Steel
- Shaft diameter: 6.0 mm
- External shaft length (mm): 32 mm
- Mounting hole pattern: 2xM4(30) + 2xM3(25)
- Laser Design: EGODRIFT Stickerbomb
- LiPo cells: 6S
- Stator diameter: 40 mm
- Stator height: 25 mm
- Stator lamination: 0.15 mm (+)
- Body Length: 52.5mm (2.07 inch)
- Diameter: 49.6mm (1.95 inch)
- Idle current: TBD
- Maximum Current: TBD
- Maximum Power: TBD
- Internal resistance: TBD
- Connection: Wire / Gold plated plugs
- Designer: Yutao Zou
